E-Log

E-log has been explicitly designed for environmental applications: it is equipped with specific inputs for a wide range of sensors and calculations of derived quantities. E-Log stores the data from the connected sensors and supports different communcation protocols both in input and output. Robust and reliable, E-Log makes measurements possible even in the most severe environments, while the 16-bit A/D converter ensures accurate and reliable data in classic meteorological, hydrological and air quality applications and – more generally – in any environmental application.

• N. 8/16 analog inputs, n.4 digital inputs,;
I• nput extension using MASTER/SLAVE configurations;
• Extremely low power consumption;
• N. 99 measurements between channels for sensor acquisition and derived quantities;
• Internal library for calculating derived quantities and mathematical calculations;
• 8MB Flash Memory;
• Modbus-RTU Master/Slave, TTY protocols;
• Model with Zig-Bee 2,4 GHz Radio for radio sensor reception and from other modules (ELO3515)
• Transmission (push) of data in ASCII format with FTP protocols;
• N. 2 RS232 ports (ELO3305);
• N. 1 RS232 port and N. 1 RS485 port (ELO3305.1);
• Digital outputs to implement external devices with programmable logics or events;
• Acquisition rate from 1 s to 12 hours;
• Elaboration rate from 1 s to 12 hours;
• Connection to the PC via RS232 (USB/Ethernet/Modem GPRS with external accessories);
• Display and keyboard.
