IQ optical spectral probes (UV-VIS) for carbon parameters and suspended solids
Optimal for the measurement of TOC and DOC in the inlet/effluent of municipal wastewater treatment plants.
Thanks to its innovative optics and spectral measuring technique, this is sensor is calibration-free. An optimized referencing ensures an excellent zero point and long-term stability. This ensures reliable measuring results! The maintenance-free WTW ultrasonic cleaning technology reduces the manual cleaning effort to a minimum.
| Measuring method | Spectral measurement in the UV-VIS range of 200-720 nm |
| Application | Infeed stimulation |
| Measuring range | 0…20000/12500 mg/l COD (tot/diss) 0…20000 mg/l TOC 0…12500 mg/l DOC 0…8000 mg/l BOD 0…5000/3000 m-1 SAC 254 (tot/diss) 0…100.0 % UVT 254 (0.00-15.00 g/l TS) |
| Cleaning | Maintenance-free WTW ultrasonic cleaning |
| Material | Saphire glass |
| IQ Sensor Net system | 282/284 and 2020 |
TOC Analyzer รุ่น AMI LineTOC ผลิตภัณฑ์ SWAN ประเทศสวิตเซอร์แลนด์ เครื่องวิเคราะห์ TOC แบบต่อเนื่องสำหรับอุตสาหกรรมยา อิเล็กทรอนิกส์ และงาน Ultrapure water
Our new QuickTOCuv II is state of the art and has more great features. LAR’s TOC analyzer QuickTOCuv II is ideal for fast and reliable online monitoring in pure, drinking, surface and wastewater.
In contrast to the standard BOD5 method the BioMonitor measures the total BOD. Measurement range: 1-200.000 mg/l BOD, 0 100 % Toxicity, Respiration in mg O2/l x min
LAR’s QuickTONultra continually monitors the TNb content of water. Optionally, further sum parameters can be detected, too. At 1,200 °C, samples are completely oxidised and only within 3 minutes the TNb result is determined.
